Disposable Deepwell Plates & Reservoirs

Features & Benefits

• Made with 100% premium Virgin Polypropylene

• Ideal for solvent resistance, minimal fluid retention and binding, and for long term -80ºC storage

• Certified RNase, DNase, protease and endotoxin free Autoclavable at 121ºC, 20 minutes, 20psi

• Optional U-bottom well design version suitable for mixing, bacterial culture, and collection of samples

• Optional V-bottom well design version to decrease dead volume

• Alphabetical labeling and cut angle mark for convenient tracking of samples; labels are molded underneath to make marking easier

• Manufactured to ANSI/SBS specifications for microplate footprint applicable to multi-channel pipettors and automated liquid handlers

• Withstand up to 4000xg

• Manufactured with new quality molds and QC-tested for flatness, providing a better surface for sealing; heat seals can be applied up to 10 times

Plates

Disposable Deepwell Plates
Click to Enlarge	Order #	Vol Wells	Well Shape	Well Bottom	Height	#/case
	DWP-16-96-SQ-U-C	1.6 ml	96	Square U	31 mm	50
	DWP-22-96-SQ-U-C	2.2 ml	96	Square U	41 mm	50
	DWP-46-48-SQ-U-C	4.6 ml	48	Square U	39 mm	50
	DWP-360-96-RD-V-C	360 ul	96	Round V	14.75 mm	100
	DWP-360-96-RD-U-C	360 ul	96	Round U	14.75 mm	100

Reserviors

Disposable Reservoirs
Click to Enlarge	Order #	Vol	Wells	Well Bottom	#/Case
	RES-180-12W (low dead volume reservoir for 12 channel pipettor)	180 ml	12	V	50
	RES-180-8W (low dead volume reservoir for 8 channel pipettor)	180 ml	12	V	50
	RES-185-384-SW (low dead volume reservoir for 384 channel pipettor)	185 ml	1	V	50
	RES-195-96-SW (low dead volume reservoir for 96 channel pipettor)	195 ml	1	V	50

Add "-S" to end of order number for sterile version for all products above.

"C" versions are clear. For colored plates replace "C" with the following: BK=black, W=white, B=blue, R=red, Y=yellow, G=Green, X=amber

Special Plates

Includes all of the features above and adds the ability to load a rack of microcentrifuge tubes with their lids locked up for access by automated liquid handlers. These are available empty or with a preloaded set of microcentrifuge tubes.

Special 24 Round Well Dual Purpose Deepwell Plates & Microcentrifuge Tube Holder
Click to Enlarge	Order #	Volume	Wells	Well Shape	Well Bottom	Height	#/case
	DWP-20-24-RD-V-C	2.0 ml	24	Round	V	49 mm	50
	DWP-24-MT-15-PPK-C (loaded with 24 1.5 ml microcentrifuge tubes)	1.5 ml	24	Round	V	49 mm	50

Cap Mats

For deepwell plates made of top grade silicon for easy and snug fit.

Cap Mats
Click to Enlarge	Order #	# Wells	Well Shape	#/case
	CM-96-SQ	96	Square	100
